Reliable LED rope light that complies with all safety requirements
ROPE LIGHT is perfect for construction site lighting and can be used as both an orientation and work light. With a length of 25 meters and an extremely high light output of 20000 lumen, this LED rope light provides optimal lighting and maximum safety on the worksite.
Compared to the previous model, this ROPE LIGHT has been improved with a practical handle and reel for winding up the rope light. LED rope lights are ideal where a long, flexible light cable is practical and useful, e.g., where light is needed for repair work inside a tank, pipe, or tunnel, or where more permanent light is needed, e.g., in stairwells during new construction.
Maximum safety
It runs on low voltage (48 V DC), which means that there is no risk of electrical shock if the rope should be accidentally pinched or cut. The light rope is made of heat-resistant silicone and is fully flexible, even in extreme cold down to -20 °C. With IP65, ROPE LIGHT is suitable for use in humid working environments. ROPE LIGHT is flicker-free, which means that there is no annoying flicker effect that can be a nuisance during work and, in the worst case, cause misjudgment of rotating tools.
It is EMC certified and in compliance with all applicable legislation in the area (EMC directive 2014/30/EU). ROPE LIGHT has a built-in power supply with temperature surveillance and a fixed 1.5-meter connection cable, making it easy to connect to a standard power socket.
To avoid overheating, always unwind the light rope completely from the drum before connecting the power. For convenient storage, the power cable can be wrapped around the drum under the light rope when not in use.
Why you should choose ROPE LIGHT:
• Reliable and flicker-free LED rope light with high IP for use in humid working environments
• Improved version with reel and handle
• EMC certified – complies with current legislation
• Low voltage (48 V DC) – no risk of life-threatening shock
• Built-in power supply with over-temperature protection and 1.5 m cable
Product Number
03.5816
EAN number
5708997358160
Product types
Floodlight
Net Weight (kg)
6.04
Length (mm)
435.00
Width (mm)
230.00
Height (mm)
260.00
Packaging
4-colour box
In the box
Rope light reel
Gross weight, packaging (kg)
6.60
Length, packaging (mm)
370.00
Width, packaging (mm)
234.00
Height, packaging (mm)
263.00
Sales display included
No
Qty in outer box
1.00
Luminous Flux, Max (Lumen)
20000
Light Source
120 LEDs/ M (25 m rope light LED strip)
CCT (Kelvin)
6000
CRI
Ra > 80
Beam Angle Main
120°
Power source
Cable
Cable
1.5 m 2 x 1 mm2 H05RN-F
Plug type
Type F (Schuko plug)
Power Consumption (W)
205.00
Operating voltage AC (V)
220-240V AC 50/60Hz
Charger included
No
Ingress protection
IP65
Impact protection
IK07
Operating temperature (°C)
-20 °C to +40 °C
Impact resistance (meter)
1.00
Product line
WORK LIGHTS
